Model		Unit	HSD-38GF	HSD-45GF	HSD-50GF	HSD-60GF	HSD-65GF	HSD-85GF	HSD-100GF
Capacity		kg	1500~3800	1500~4500	1500~5000	1500~6000	1500~6500	2500~8500	2500~10000
Size	Length	mm	3520
	Width	mm	1650
	Height	mm	4760	5110	5370	5720	5990	6950	7560
Weight		kg	1460	1510	1550	1600	1640	1840	1930
Fan	Type		Axial Type, Belt Driving Type
	Diameter	mm	∅580
	R.P.M	r.p.m	1950
Hot-air source			Gun Type burner or Husk Furnace
Fuel			Kerosene, Diesel, Husk, Corn Cob, Wood Pellets
Power		kw	Single Phrase 220[V], Three Phrase 380[V], 3.36kw					4.11kw
Power		Required	Single Phrase 220[V], Three Phrase 380[V], Over 5.0kw(Recommended)
Performance	Loading	min	12~20	19~23	24~27	28~33	35~38	40~45	51~60
	Discharging	min	22~25	23~26	29~35	35~40	38~45	50~57	60~67
	Drying Rate	%/hr	0.7~1.0
Safety and relates device			Wind Pressure Switch, Auto-Temperature Controller, Magnet, Timer, Alarming Device(Buzzer), Over-loading Sensor, Auto-Moisture Detector, Detector(GM Series), Fire Extinguisher

Raw Paddy Dryer
